ROBUR

Automatic rotating-basket metal washer for large volumes and weights

ROBUR is a line of automatic rotating-basket parts washers designed for washing parts of large dimensions and considerable weight. The washing process takes place through upper, lower, and side jets, while the platform rotates slowly thanks to a gear motor with a torque limiter, guaranteeing operational stability even with high loads. Management is entrusted to a PLC, which allows for a high possibility of customization of the washing cycles, supported by a vast choice of accessories. The large-capacity tank, separate from the washing chamber and located on the right side of the machine, optimizes the management of the washing bath for major workloads.

Robur line

Request Information

Washing Area

Up to Ø 225 x H 100 cm

Loading Capacity

Up to 800 kg

Maximum Temperature

Up to 80 °C

Version

LT (heating up to 60° C) - HT (heating up to 80° C)

Controls

PLC with Color Touchscreen, Industry 4.0 Option

Tanks

Single tank, Tank separated from the washing chamber

Power Supply

Three-phase

Detergent

CLEAN POWER, SAX Q, 545, ADD-SGX, SG233A, NEW 105, XL10, PROMETAL, PROTEK-IN, ADD-SGX, DROPAWAY, ASH, DEOXY, PUL-T

Features

Details

Accessories

Models

What is included in all ROBUR models

Pneumatic opening and closing of the lid with 2-hand safety control
Timed electric vapor extraction
External trolley in AISI 304 stainless steel with drip tray and wheels with safety brake
ISO pneumatic cylinders and pneumatic “anti-fall” safety valves
Tank thermal insulation with AISI 430 stainless steel panels
Siemens® power electrical components
4″ color Touchscreen display for settings and programs
Cassette filter with 6 vertical filters in AISI 304 for pre-filtering the return liquid into the tank
AISI 304 stainless steel filter on the pump suction
Triple door seal (lower, upper, and side) and seals on all tank covers
Structure and sheets in contact with the liquid in AISI 304 stainless steel
Minimum level control
Dispensed pressure control gauge
Safety limit switch on door opening
Gear motor for basket rotation with torque limiter and centering sensor
Sludge discharge door for simple tank cleaning
Reinforced platform in pressed grating with raised outer edge in galvanized steel
Multistage vertical electric pump in AISI 304 stainless steel with special seals
Manually adjustable washing pressure
Weekly programming for heating ignition and oil skimmer (if installed)
IP65 electrical system, managed with touchscreen PLC (DGT V4)
Liquid heating with stainless steel electric resistance
Internal weld bleaching
Tanks accessible from the outside
Lower load-bearing structure in stainless steel
Washing pipes in AISI 304 stainless steel with professional stainless steel blade nozzles
Drain valves for tank emptying
Manual valve for water filling

HT VERSION

Thermal insulation with AISI 430 stainless steel panels

The parts washers of the Robur range are aimed at washing processes where maximum quality and reliability are necessary. They are equipped with an external trolley on which the parts to be treated are placed. The operator then slides the platform containing the parts into the washing cabin, closes the vertical door using a two-hand control, and starts the work cycle. Washing is performed by means of a vertical stainless steel pump that sucks the liquid from the tank and sprays it onto the parts while the platform is rotated slowly by means of a gear motor. The system is fully configurable thanks to the numerous accessories available and the work cycle is totally managed by an industrial PLC. On the color touchscreen mounted on the front of the machine, it is possible to modify work parameters such as liquid temperature, on/off times, check the operation of each installed device, and modify the 16 available washing programs. Robur parts washers are extremely solid and long-lasting, allowing operator times to be reduced while always guaranteeing results exceeding expectations. Thanks to some customizations such as motorized platform movement and motorized rotation of the jets, it is possible to configure the parts washer to wash parts weighing over 4000 kg. Some available accessories are heating with gas or diesel burner, high-pressure pump, manual washing integrated into the machine, hot air drying.

Main operational benefits:

Automatic washing of components of large dimensions and weight
Upper, lower, and side jets for uniform action on the entire surface
Rotating platform with gear motor and torque limiter
Programming via PLC for customizable cycles
Separate tank from the washing chamber
Compatibility with accessories for tailor-made configurations
Industry 4.0 and 5.0 ready (optional)
Possibility of washing components over 4000 kg in weight.

Technical positioning:

Industrial automatic metal washer for heavy loads
Line for automatic treatment of large parts
High-performance technical washing plant

What can be added as an accessory

Maximum liquid level control in the tank and filling solenoid valve
Compressed air blowing
Drying with resistance and side channel blower with air blade
Load capacity increased by [QTY] x 100 kg
Mixed resin demineralizer with conductivity meter
Increased washing height
Centrifugal vapor condenser S
Centrifugal vapor condenser M
Additional steel basket/platform
Additional external trolley in AISI 304 stainless steel
Automatic liquid detergent dispenser
Disc oil skimmer with independent motorization
External pneumatic oil skimmer
Stainless steel bag filter
Magnetic candle for bag filter for ferritic powder
Device for remote connection and tele-assistance for Weintek HMI
Industry 4.0 ready for Weintek HMI
Manual washing and blowing with hoses and washing lance
80 bar washing and manual blowing with hoses and washing lance
Motorized platform loading and unloading movement [C]
Setup for the use of abrasive contaminants in the washing liquid
Stainless steel fittings and valves in contact with the liquid (KIT FC)
Siemens S7 1200 PLC – Weintek touchscreen HMI
High-pressure washing pump
Insulated stainless steel roller shutter front door
Platform and spokes in AISI 304 stainless steel
Heating with diesel / methane burner
Drip collection retention tank in AISI 304 stainless steel
Nebulized rinse from water mains and drain into the tank
Compressed air blowing with height-adjustable upper pipe
Removable sides for grating, H200 mm, in stainless steel
Tank emptying pump
Signal tower for plant status identification
External loading and unloading station (second platform included) [C]
Industry 4.0 ready for Weintek HMI
Industry 4.0 ready for Siemens PLC
Industry 5.0 ready (Energy counter)

ACCESSORIES LEGEND

C: useful washing height is reduced by 130 mm

Model	Washing Capacity (Ø x H)	Basket Capacity	Tank
R 1000	Ø 90 x H 70 cm	600 Kg	450 lt
R 1200	Ø 110 x H 80 cm	600 Kg	550 lt
R 1400	Ø 128 x H 90 cm	600 Kg	750 lt
R 1800	Ø 165 x H 100 cm	800 Kg	1000 lt
R 2200	Ø 200 x H 100 cm	800 Kg	1200 lt
R 2600	Ø 225 x H 100 cm	800 Kg	1200 lt
