ROBUR 2B

Automatic rotating-basket metal washer with double tank

ROBUR 2B is a line of automatic rotating-basket parts washers designed for washing large and considerably heavy components, with a double tank system for washing and rinsing. The treatment takes place via upper, lower, and side jets, while the slow rotation of the platform is guaranteed by a gear motor with a torque limiter, ensuring stability and control even with high loads. Management via PLC allows for high customization of the work cycles, supported by a wide availability of accessories. In this configuration, the plant has two separate tanks, dedicated respectively to washing and rinsing, improving the effectiveness of the process and the quality of the final result.

Robur line

Request Information

Washing Area

Up to Ø 225 x H 100 cm

Loading Capacity

Up to 800 kg

Maximum Temperature

Up to 80 °C

Version

LT (heating up to 60° C), HT (heating up to 80° C)

Controls

PLC with Color Touchscreen, Industry 4.0 and 5.0 Option

Tanks

Double tank (wash + rinse)

Power Supply

400V 3 PH 50 HZ

Detergent

CLEAN POWER, SAX Q, 545, ADD-SGX, SG233A , NEW 105, XL10, PROMETAL, PROTEK-IN, ADD-SGX, DROPAWAY, ASH, DETERFOS, DEOXY, PUL-T

Features

Details

Accessories

Models

What is included in all ROBUR 2B models

Pneumatic opening and closing of the lid with 2-hand safety control
Timed electric vapor extraction
External trolley in AISI 304 stainless steel with drip tray and wheels with safety brake
ISO pneumatic cylinders and pneumatic “anti-fall” safety valves
Tank thermal insulation with AISI 430 stainless steel panels
Siemens® power electrical components
4″ color Touchscreen display for settings and programs
Cassette filter with 6 vertical filters in AISI 304 for pre-filtering the return liquid into the tank
AISI 304 stainless steel filter on the pump suction
Triple door seal (lower, upper, and side) and seals on all tank covers
Structure and sheets in contact with the liquid in AISI 304 stainless steel
Minimum level control
Dispensed pressure control gauge
Safety limit switch on door opening
Gear motor for basket rotation with torque limiter and centering sensor
Sludge discharge door for simple tank cleaning
Reinforced platform in pressed grating with raised outer edge in galvanized steel
Multistage vertical electric pump in AISI 304 stainless steel with special seals
Manually adjustable washing pressure
Weekly programming for heating ignition and oil skimmer (if installed)
IP65 electrical system, managed with touchscreen PLC (DGT V4)
Liquid heating with stainless steel electric resistance
Internal weld bleaching
Tanks accessible from the outside
Lower load-bearing structure in stainless steel
Washing pipes in AISI 304 stainless steel with professional stainless steel blade nozzles
Drain valves for tank emptying
Manual valve for water filling

HT VERSION

Thermal insulation with AISI 430 stainless steel panels

Robur 2B (double tank) parts washers allow the washing and rinsing of medium and large parts and heavy weights. Loading parts onto Robur 2B is done by placing the items to be washed on an external trolley positioned in front of the machine. After inserting the platform into the washing cabin, the front vertical door is closed and the washing cycle is started. Washing is performed by means of a stainless steel pump that sucks the liquid from the first tank and sprays it onto the parts while the platform is rotated slowly by means of a gear motor. Once washing is complete, the parts are rinsed: in this phase, a second pump sucks the rinsing liquid from the second tank and sprays it onto the parts via dedicated pipes. The system is fully configurable thanks to the numerous accessories available, and it is also possible to customize the parts washer according to the customer’s needs. All work parameters can be modified and monitored via the touchscreen panel installed on the control panel. Robur 2B parts washers are extremely robust and long-lasting and allow operator times to be drastically cut, guaranteeing process repeatability thanks to high reliability. Thanks to some accessories such as motorized platform movement and motorized rotation of the washing and rinsing jets, the load capacity can exceed 4000 kg.

Main operational benefits:

Automatic washing for large and heavy parts
Double tank system for separate washing and rinsing
Upper, lower, and side jets for uniform treatment
Rotating platform with gear motor and torque limiter
Cycle management via PLC with wide customization possibilities
Industry 4.0 and 5.0 ready (optional)
Wide range of accessories for tailor-made configurations

Technical positioning:

Industrial automatic metal washer for heavy loads
Professional double tank system for washing and rinsing
Plant designed for structured production and high loads

What can be added as an accessory

Maximum liquid level control in the tank and filling solenoid valve
Compressed air blowing
Drying with resistance and side channel blower with air blade
Load capacity increased by [QTY] x 100 kg
Mixed resin demineralizer with conductivity meter
Increased washing height
Centrifugal vapor condenser S
Centrifugal vapor condenser M
Additional steel basket/platform
Additional external trolley in AISI 304 stainless steel
Automatic liquid detergent dispenser
Disc oil skimmer with independent motorization
External pneumatic oil skimmer
Stainless steel bag filter
Magnetic candle for bag filter for ferritic powder
Device for remote connection and tele-assistance for Weintek HMI
Industry 4.0 ready for Weintek HMI
Manual washing and blowing with hoses and washing lance
80 bar washing and manual blowing with hoses and washing lance
Motorized platform loading and unloading movement [C]
Setup for the use of abrasive contaminants in the washing liquid
Stainless steel fittings and valves in contact with the liquid (KIT FC)
Siemens S7 1200 PLC – Weintek touchscreen HMI
High-pressure washing pump
High-pressure rinsing pump
Booster pump from cleaner tank to more contaminated tank
Insulated stainless steel roller shutter front door
Platform and spokes in AISI 304 stainless steel
Drip collection retention tank in AISI 304 stainless steel
Mains water rinsing and drain-to-waste
Nebulized rinse from water mains and drain into the tank
Compressed air blowing with height-adjustable upper pipe
Removable sides for grating, H200 mm, in stainless steel
Tank emptying pump (2)
Signal tower for plant status identification
External loading and unloading station (second platform included) [C]
Industry 4.0 ready for Weintek HMI
Industry 4.0 ready for Siemens PLC
Industry 5.0 ready (Energy counter)

ACCESSORIES LEGEND

C: useful washing height is reduced by 130 mm

Model	Washing Capacity (Ø x H)	Basket Capacity	Tank
R 1000	Ø 90 x H 70 cm	600 Kg	300 lt
R 1200	Ø 110 x H 80 cm	600 Kg	400 lt
R 1400	Ø 128 x H 90 cm	600 Kg	500 lt
R 1800	Ø 165 x H 100 cm	800 Kg	700 lt
R 2200	Ø 200 x H 100 cm	800 Kg	800 lt
R 2600	Ø 225 x H 100 cm	800 Kg	800 lt
