TWISTER
Spray metal washer with continuous rotation on basket
Washing Area
Crate 30 x 45 x H30 cm
Loading Capacity
80 kg
Maximum Temperature
Up to 80 °C
Version
LT (heating up to 60° C) - HT (heating up to 80° C)
Controls
PLC with Color Touchscreen, Industry 4.0 and 5.0 Option
Tanks
Single tank
Power Supply
Three-phase
Detergent
CLEAN POWER, SAX Q, 545, ADD-SGX, SG233A, NEW 105, XL10, PROMETAL, PROTEK-IN, ADD-SGX, DROPAWAY, ASH, DEOXY, PUL-T
Features
Details
Accessories
Models
What is included in all TWISTER models
- Assisted door closure with gas springs and closing hook
- Siemens® power electrical components
- 4″ color touchscreen display for settings and programs
- AISI 304 stainless steel filter on the pump suction
- Tank edge gasket
- Structure and sheets in contact with the liquid in AISI 304 stainless steel
- Minimum level control
- Safety limit switch on lid opening
- Stainless steel electric pump with special seals
- Weekly programming for heating ignition
- Oil skimmer (if installed)
- IP65 electrical system, managed with touchscreen PLC (DGT V4)
- Liquid heating with stainless steel electric resistance
- Mechanical rotation of the basket via gear motor
- Internal weld bleaching
- Flexible pump suction and delivery pipes (easy maintenance)
- Washing pipes in AISI 304 stainless steel with professional stainless steel blade nozzles
- Drain valves for tank emptying
- Manual valve for water filling
Main operational benefits:
- Spray washing of parts in crate
- Continuous rotation along horizontal axis
- Safe insertion of parts in electro-welded stainless steel crates
- Suitable for small and medium-sized parts
- PLC management with color touchscreen
- Industry 4.0 and 5.0 ready (optional)
Technical positioning:
- Automatic metal washer for controlled washing cycles
- Ideal for laboratories and production departments with medium-low volumes
- Compact and simple to integrate system
- Solution for crate washing lines with continuous rotation
What can be added as an accessory
- Maximum liquid level control in the tank and filling solenoid valve
- Compressed air blowing [B]
- Drying with resistance and side channel blower with air blade [B]
- Timed electric vapor extraction [A]
- Centrifugal vapor condenser S on trolley [D]
- Automatic liquid detergent dispenser, installed on bath 1
- Disc oil skimmer with independent motorization
- Stainless steel bag filter, installed on bath 1
- Magnetic candle for bag filter for ferritic powder
- Device for remote connection and tele-assistance for Weintek HMI
- Industry 4.0 ready for Weintek HMI
- Motorized stainless steel rotating basket kit
- Setup for the use of abrasive contaminants in the washing liquid
- Stainless steel fittings and valves in contact with the liquid (KIT FC)
- Siemens S7 1200 PLC – Weintek touchscreen HMI
- High-pressure washing pump
- Panels under basket with grease and solid collection well filters
- Drip collection retention tank in AISI 304 stainless steel
- Nebulized rinse from water mains and drain into the tank
- Machine equipped with wheels for movement
- Tank emptying pump
- Signal tower for plant status identification
- Stainless steel crate with lid
- Industry 4.0 ready for Weintek HMI
- Industry 4.0 ready for Siemens PLC
- Industry 5.0 ready (Energy counter)
HT VERSION
- Electric vapor extraction
- Thermal insulation with AISI 430 stainless steel panels
- Safety limit switch with lid opening lock during the cycle
- Panels under basket with grease and solid collection well filters
ACCESSORIES LEGEND
A: extraction is included in the HT version
B: panels under basket are mandatory (if present in the list for that model)
D: vapor extraction is mandatory (if present in the list for that model)
| Model | Washing Area | Load capacity | Tank | |
|---|---|---|---|---|
| TW80 | Cassette 30 x 45 x H30 cm | 80 Kg | 160 lt |
